品牌：SIEMENS（西门子）（原LANDIS&GYR品牌）
产地：德国
颜色：暗红 加长
Photoresistive flame detectors for use with Landis & Staefa burner controls, for the supervision of oil flames in the visible light spectrum. The flame detectors are used primarily in connection with burner controls for small burners.
-
With this type of flame supervision, the radiation of oil flames in the visible light spectrum is used for generating the flame signal.
-
The light-sensitive element is a photoresistor.
-
When there is no light, the detector′s resistance is in the MΩrange.
-
The resistance drops as the intensity of illumination increases (kΩrange).
-
In contrast to the selenium photocell of the RAR... detectors, glowing firebrick in the combustion chamber can be detected.
|
主要参数
|
|
保护等级
|
IP40
|
|
当连接至LOA.../LAL...时，电缆长度
|
1.5m最大
|
|
连接电缆
|
2*0.75mm2,5.1mm直径
|
|
重量
|
20...35g
|
|
|
环境条件
|
|
运输环境
|
IEC 60 721-3-2
|
|
内部条件
|
class 2K2
|
|
温度范围
|
-20...+60oC
|
|
湿度
|
<95%
|
|
运行环境
|
IEC 60 721-3-3
|
|
内部条件
|
class 3K5
|
|
机械条件
|
class 3M2
|
|
温度范围
|
-20...+60oC
|
|
湿度
|
<95%
|
|
不得进水
|
|
此型号主要应用于瑞典百通ST133机型内。
